This line processes rigid plastic scrap into clean, dry flakes ready for pelletizing. It starts with a heavy-duty crusher, then moves through hot washing with detergent, high-speed friction washing, a float-sink separation tank to remove caps and labels, and finally a dewatering and drying stage.
Water is recirculated through settling tanks to reduce make-up water and discharge volume — increasingly important for environmental compliance. Worn blades are replaceable individually.
Key features
Heavy-duty crusher with replaceable, individually adjustable blades
Hot wash + friction wash for label and glue removal
Float-sink tank separates caps, labels and contaminants
Dewatering and hot-air drying to low residual moisture
Recirculated water system reduces consumption and discharge
Technical specifications
Parameter
Value
Model
MX-PW500 / MX-PW1000 / MX-PW2000
Capacity
0.5 / 1 / 2 tonnes per hour
Crusher Power
22 – 75 kW
Wash Stages
Hot wash, friction wash, rinse, float-sink
Drying
Dewatering + hot air drying
Voltage
380 V, 50 Hz
Total Power
60 – 220 kW
Water Use
Recirculating with settling tank
Material
SUS 304 wash tanks, alloy steel blades
Warranty
12 months
Typical applications
PET bottles, HDPE crates, PP containers, PE film, PVC profile, rigid plastic recycling.
Packing & shipping
The machine is wrapped in plastic film, fixed on a steel pallet or in a plywood case, then loaded and secured inside the container. We supply the packing list, commercial invoice, bill of lading and certificate of origin. Fumigation and marine insurance can be arranged on request.
Tell us the machine you need — get a full quotation in 12 hours
Send us your capacity target, product type, voltage and destination port. Our engineers will recommend the right model, confirm price and lead time, and quote shipping to your door.
