The MX-FM line takes grain, cake meal and additives through grinding, batching by weight, ribbon mixing and — optionally — pelletising and cooling. The batching controller stores formulas so operators simply select a recipe and quantity.
A double-ribbon mixer achieves over 95% mixing uniformity, and the pellet mill uses a conditioned die to produce durable feed pellets with low fines. Considering the whole line, power consumption per tonne is kept low through correctly sized motors and drives.
Key features
Formula-based automatic batching and weighing
Double-ribbon mixer with >95% uniformity
Optional pellet mill with steam conditioning
Dust collection and cyclone separation
Modular layout adapted to your building
Technical specifications
Parameter
Value
Model
MX-FM1000 / MX-FM2000 / MX-FM5000
Capacity
1 / 3 / 10 tonnes per hour
Mixer Uniformity
≥ 95%
Weighing Accuracy
± 0.5%
Voltage
380 V, 50 Hz
Total Power
35 – 180 kW
Pellet Size
2 – 8 mm (die dependent)
Material
Carbon steel, SUS 304 option
Warranty
12 months
Typical applications
Poultry feed, cattle feed, pig feed, aquatic feed, small feed mills and farm feed plants.
Packing & shipping
The machine is wrapped in plastic film, fixed on a steel pallet or in a plywood case, then loaded and secured inside the container. We supply the packing list, commercial invoice, bill of lading and certificate of origin. Fumigation and marine insurance can be arranged on request.
Tell us the machine you need — get a full quotation in 12 hours
Send us your capacity target, product type, voltage and destination port. Our engineers will recommend the right model, confirm price and lead time, and quote shipping to your door.
