The MX-VC cutting line combines a dicer with an optional slicer and strip cutter on one conveyor-driven line. Blade assemblies are mounted on quick-release cassettes, so switching from 10 mm dice to 3 mm slices takes minutes rather than hours.
A vibratory or belt infeed spreads product evenly across the cutting head, which is essential for a consistent cut and for protecting the blades. The whole cutting chamber swings open for cleaning.
Key features
Interchangeable dice, slice, strip and shred cassettes
Even product distribution protects blades and ensures uniformity
Cutting chamber opens fully for fast sanitation
Variable speed infeed conveyor
Blade material options for acidic produce
Technical specifications
Parameter
Value
Model
MX-VC300 / MX-VC500 / MX-VC1000
Capacity
0.5 / 1.5 / 3 tonnes per hour
Cut Size
Dice 3–25 mm, slice 1–20 mm, strip configurable
Blade Material
SUS 420 / ceramic optional
Voltage
380 V, 50 Hz
Power
3 – 8 kW
Material
SUS 304, food-grade belt
Dimension
3,200 × 900 × 1,500 mm
Warranty
12 months
Typical applications
Pre-cut vegetable, salad bar supply, frozen vegetable, dried fruit, restaurant central kitchen.
Packing & shipping
The machine is wrapped in plastic film, fixed on a steel pallet or in a plywood case, then loaded and secured inside the container. We supply the packing list, commercial invoice, bill of lading and certificate of origin. Fumigation and marine insurance can be arranged on request.
Tell us the machine you need — get a full quotation in 12 hours
Send us your capacity target, product type, voltage and destination port. Our engineers will recommend the right model, confirm price and lead time, and quote shipping to your door.
